ТС RU K-DE.МТ02.00031.Р5
![](http://media.hpt.su/cache/20/5b/205b73ab9e1da54d80aec9c7cf564796.jpg)
ОТШ ТС RU K-DE.МТ02.00031.Р5
Эскиз первого листа
из 23.
Документ НЕ полный!
Отсутствуют:
титульный лист;
разделительный перечень;
описание маркировки;
габаритные чертежи.
Общие сведения |
|
---|---|
Номер документа | ТС RU К-DE.МТ02.00031.Р5 |
Номер бланка | 0002461 |
Дата оформления | 05.04.2021 |
Специальные сведения |
|
Код VIN | WMA???ZZ????????? |
Сведения об автомобиле |
|
Марка ТС | MAN |
Коммерческое наименование | TGX, TGS |
Тип ТС | L.2007.46.003 |
Модификации | 32.320 8x4 BB-WW, 32.320 8x4 BB, 32.320 8x4 BB CH, 35.320 8x2-4 BL, ; 35.320 8x4 BB, 35.320 8x4 BL, 35.320 8x6H BL, 35.320 8x4H-6 BL, ; 35.320 8x4-4 BL, 35.320 8x6 BB, 35.320 8x8 BB, 35.320 8x4 BB CH, ; 35.320 8x4 BL CH, 35.320 8x6H BL CH, 35.320 8x4H-6 BL CH, 35.320 ; 8x2-4 BL CH, 35.320 8x2-6 BL CH, 35.320 8x4-4 BL CH, 35.320 8x6 BB ; CH, 35.320 8x8 BB CH, 35.320 8x2=4 BL CH, 37.320 8x4 BB, 41.320 8x4 ; BB, 41.320 8x4 BB-WW, 41.320 8x6 BB, 41.320 8x8 BB-WW, 41.320 8x8 ; BB, 41.320 8x4 BB CH, 41.320 8x6 BB CH, 41.320 8x8 BB CH, 32.330 ; 8x4 BB-WW, 32.330 8x4 BB, 32.330 8x4 BB CH, 35.330 8x2-4 BL, 35.330 ; 8x4 BB, 35.330 8x4 BL, 35.330 8x6H BL, 35.330 8x4H-6 BL, 35.330 8x4-4 ; BL, 35.330 8x6 BB, 35.330 8x8 BB, 35.330 8x4 BB CH, 35.330 8x4 BL ; CH, 35.330 8x6H BL CH, 35.330 8x4H-6 BL CH, 35.330 8x2-4 BL CH, ; 35.330 8x2-6 BL CH, 35.330 8x4-4 BL CH, 35.330 8x6 BB CH, 35.330 8x8 ; BB CH, 35.330 8x2=4 BL CH, 37.330 8x4 BB, 41.330 8x4 BB, 41.330 8x4 ; BB-WW, 41.330 8x6 BB, 41.330 8x8 BB-WW, 41.330 8x8 BB, 41.330 8x4 ; BB CH, 41.330 8x6 BB CH, 41.330 8x8 BB CH, 32.360 8x4 BB-WW, ; 32.360 8x4 BB, 32.360 8x4 BB CH, 35.360 8x2-4 BL, 35.360 8x4 BB, ; 35.360 8x4 BL, 35.360 8x6H BL, 35.360 8x4H-6 BL, 35.360 8x4-4 BL, ; 35.360 8x6 BB, 35.360 8x8 BB, 35.360 8x4 BB CH, 35.360 8x4 BL CH, ; 35.360 8x6H BL CH, 35.360 8x4H-6 BL CH, 35.360 8x2-4 BL CH, 35.360 ; 8x2-6 BL CH, 35.360 8x4-4 BL CH, 35.360 8x6 BB CH, 35.360 8x8 BB ; CH, 35.360 8x2=4 BL CH, 37.360 8x4 BB, 41.360 8x4 BB, 41.360 8x4 ; BB-WW, 41.360 8x6 BB, 41.360 8x8 BB-WW, 41.360 8x8 BB, 41.360 8x4 ; BB CH, 41.360 8x6 BB CH, 41.360 8x8 BB CH, 32.400 8x4 BB-WW, ; 32.400 8x4 BB, 32.400 8x4 BB CH, 35.400 8x2-4 BL, 35.400 8x4 BB, ; 35.400 8x4 BL, 35.400 8x6H BL, 35.400 8x4H-6 BL, 35.400 8x4-4 BL, ; 35.400 8x6 BB, 35.400 8x8 BB, 35.400 8x4 BB CH, 35.400 8x4 BL CH, ; 35.400 8x6H BL CH, 35.400 8x4H-6 BL CH, 35.400 8x2-4 BL CH, 35.400 ; 8x2-6 BL CH, 35.400 8x4-4 BL CH, 35.400 8x6 BB CH, 35.400 8x8 BB ; CH, 35.400 8x2=4 BL CH, 37.400 8x4 BB, 41.400 8x4 BB, 41.400 8x4 ; BB-WW, 41.400 8x6 BB, 41.400 8x8 BB-WW, 41.400 8x8 BB, 41.400 8x4 ; BB CH, 41.400 8x6 BB CH, 41.400 8x8 BB CH, 32.420 8x4 BB-WW, 32.420 8x4 BB, 32.420 8x4 BB CH, 35.420 8x2-4 BL, 35.420 8x4 BB, ; 35.420 8x4 BL, 35.420 8x6H BL, 35.420 8x4H-6 BL, 35.420 8x4-4 BL, ; 35.420 8x6 BB, 35.420 8x8 BB, 35.420 8x4 BB CH, 35.420 8x4 BL CH, ; 35.420 8x6H BL CH, 35.420 8x4H-6 BL CH, 35.420 8x2-4 BL CH, 35.420 ; 8x2-6 BL CH, 35.420 8x4-4 BL CH, 35.420 8x6 BB CH, 35.420 8x8 BB ; CH, 35.420 8x2=4 BL CH, 37.420 8x4 BB, 41.420 8x4 BB, 41.420 8x4 ; BB-WW, 41.420 8x6 BB, 41.420 8x8 BB-WW, 41.420 8x8 BB, 41.420 8x4 ; BB CH, 41.420 8x6 BB CH, 41.420 8x8 BB CH, 32.430 8x4 BB-WW, ; 32.430 8x4 BB, 32.430 8x4 BB CH, 35.430 8x2-4 BL, 35.430 8x4 BB, ; 35.430 8x4 BL, 35.430 8x6H BL, 35.430 8x4H-6 BL, 35.430 8x4-4 BL, ; 35.430 8x6 BB, 35.430 8x8 BB, 35.430 8x4 BB CH, 35.430 8x4 BL CH, ; 35.430 8x6H BL CH, 35.430 8x4H-6 BL CH, 35.430 8x2-4 BL CH, 35.430 ; 8x2-6 BL CH, 35.430 8x4-4 BL CH, 35.430 8x6 BB CH, 35.430 8x8 BB ; CH, 35.430 8x2=4 BL CH, 37.430 8x4 BB, 41.430 8x4 BB, 41.430 8x4 ; BB-WW, 41.430 8x6 BB, 41.430 8x8 BB-WW, 41.430 8x8 BB, 41.430 8x4 ; BB CH, 41.430 8x6 BB CH, 41.430 8x8 BB CH, 32.440 8x4 BB-WW, ; 32.440 8x4 BB, 32.440 8x4 BB CH, 35.440 8x2-4 BL, 35.440 8x4 BB, ; 35.440 8x4 BL, 35.440 8x6H BL, 35.440 8x4H-6 BL, 35.440 8x4-4 BL, ; 35.440 8x6 BB, 35.440 8x8 BB, 35.440 8x4 BB CH, 35.440 8x4 BL CH, ; 35.440 8x6H BL CH, 35.440 8x4H-6 BL CH, 35.440 8x2-4 BL CH, 35.440 ; 8x2-6 BL CH, 35.440 8x4-4 BL CH, 35.440 8x6 BB CH, 35.440 8x8 BB ; CH, 35.440 8x2=4 BL CH, 37.440 8x4 BB, 41.440 8x4 BB, 41.440 8x4 ; BB-WW, 41.440 8x6 BB, 41.440 8x8 BB-WW, 41.440 8x8 BB, 41.440 8x4 ; BB CH, 41.440 8x6 BB CH, 41.440 8x8 BB CH, 32.460 8x4 BB, 32.460 ; 8x4 BB CH, 32.460 8x4 BB-WW, 35.460 8x2-4 BL, 35.460 8x4 BB, 35.460 ; 8x4 BL, 35.460 8x6H BL, 35.460 8x4H-6 BL, 35.460 8x4-4 BL, 35.460 8x6 ; BB, 35.460 8x8 BB, 35.460 8x4 BB CH, 35.460 8x4 BL CH, 35.460 8x6H ; BL CH, 35.460 8x4H-6 BL CH, 35.460 8x2-4 BL CH, 35.460 8x2-6 BL CH, ; 35.460 8x4-4 BL CH, 35.460 8x6 BB CH, 35.460 8x8 BB CH, 35.460 ; 8x2=4 BL CH, 37.460 8x4 BB, 41.460 8x4 BB, 41.460 8x4 BB-WW, ; 41.460 8x6 BB, 41.460 8x8 BB-WW, 41.460 8x8 BB, 41.460 8x4 BB CH, ; 41.460 8x6 BB CH, 41.460 8x8 BB CH, 32.470 8x4 BB-WW, 32.470 8x4 ; BB, 32.470 8x4 BB CH, 35.470 8x2-4 BL, 35.470 8x4 BB, 35.470 8x4 BL, ; 35.470 8x6H BL, 35.470 8x4H-6 BL, 35.470 8x4-4 BL, 35.470 8x6 BB, ; 35.470 8x8 BB, 35.470 8x4 BB CH, 35.470 8x4 BL CH, 35.470 8x6H BL ; CH, 35.470 8x4H-6 BL CH, 35.470 8x2-4 BL CH, 35.470 8x2-6 BL CH, 35.470 8x4-4 BL CH, 35.470 8x6 BB CH, 35.470 8x8 BB CH, 35.470 ; 8x2=4 BL CH, 37.470 8x4 BB, 41.470 8x4 BB, 41.470 8x4 BB-WW, ; 41.470 8x6 BB, 41.470 8x8 BB-WW, 41.470 8x8 BB, 41.470 8x4 BB CH, ; 41.470 8x6 BB CH, 41.470 8x8 BB CH, 32.480 8x4 BB-WW, 32.480 8x4 ; BB, 32.480 8x4 BB CH, 35.480 8x2-4 BL, 35.480 8x4 BB, 35.480 8x4 BL, ; 35.480 8x6H BL, 35.480 8x4H-6 BL, 35.480 8x4-4 BL, 35.480 8x6 BB, ; 35.480 8x8 BB, 35.480 8x4 BB CH, 35.480 8x4 BL CH, 35.480 8x6H BL ; CH, 35.480 8x4H-6 BL CH, 35.480 8x2-4 BL CH, 35.480 8x2-6 BL CH, ; 35.480 8x4-4 BL CH, 35.480 8x6 BB CH, 35.480 8x8 BB CH, 35.480 ; 8x2=4 BL CH, 37.480 8x4 BB, 41.480 8x4 BB, 41.480 8x4 BB-WW, ; 41.480 8x6 BB, 41.480 8x8 BB-WW, 41.480 8x8 BB, 41.480 8x4 BB CH, ; 41.480 8x6 BB CH, 41.480 8x8 BB CH, 32.500 8x4 BB-WW, 32.500 8x4 ; BB, 32.500 8x4 BB CH, 35.500 8x2-4 BL, 35.500 8x4 BB, 35.500 8x4 BL, ; 35.500 8x6H BL, 35.500 8x4H-6 BL, 35.500 8x4-4 BL, 35.500 8x6 BB, ; 35.500 8x8 BB, 35.500 8x4 BB CH, 35.500 8x4 BL CH, 35.500 8x6H BL ; CH, 35.500 8x4H-6 BL CH, 35.500 8x2-4 BL CH, 35.500 8x2-6 BL CH, ; 35.500 8x4-4 BL CH, 35.500 8x6 BB CH, 35.500 8x8 BB CH, 35.500 ; 8x2=4 BL CH, 37.500 8x4 BB, 41.500 8x4 BB, 41.500 8x4 BB-WW, ; 41.500 8x6 BB, 41.500 8x8 BB-WW, 41.500 8x8 BB, 41.500 8x4 BB CH, 41.500 8x6 BB CH, 41.500 8x8 BB CH, 32.510 8x4 BB-WW, 32.510 8x4 ; BB, 32.510 8x4 BB CH, 35.510 8x2-4 BL, 35.510 8x4 BB, 35.510 8x4 BL, ; 35.510 8x6H BL, 35.510 8x4H-6 BL, 35.510 8x4-4 BL, 35.510 8x6 BB, ; 35.510 8x8 BB, 35.510 8x4 BB CH, 35.510 8x4 BL CH, 35.510 8x6H BL ; CH, 35.510 8x4H-6 BL CH, 35.510 8x2-4 BL CH, 35.510 8x2-6 BL CH, ; 35.510 8x4-4 BL CH, 35.510 8x6 BB CH, 35.510 8x8 BB CH, 35.510 ; 8x2=4 BL CH, 37.510 8x4 BB, 41.510 8x4 BB, 41.510 8x4 BB-WW, ; 41.510 8x6 BB, 41.510 8x8 BB-WW, 41.510 8x8 BB, 41.510 8x4 BB CH, ; 41.510 8x6 BB CH, 41.510 8x8 BB CH, 32.540 8x4 BB-WW, 32.540 8x4 ; BB, 32.540 8x4 BB CH, 35.540 8x2-4 BL, 35.540 8x4 BB, 35.540 8x4 BL, ; 35.540 8x6H BL, 35.540 8x4H-6 BL, 35.540 8x4-4 BL, 35.540 8x6 BB, ; 35.540 8x8 BB, 35.540 8x4 BB CH, 35.540 8x4 BL CH, 35.540 8x6H BL ; CH, 35.540 8x4H-6 BL CH, 35.540 8x2-4 BL CH, 35.540 8x2-6 BL CH, ; 35.540 8x4-4 BL CH, 35.540 8x6 BB CH, 35.540 8x8 BB CH, 35.540 ; 8x2=4 BL CH, 37.540 8x4 BB, 41.540 8x4 BB, 41.540 8x4 BB-WW, ; 41.540 8x6 BB, 41.540 8x8 BB-WW, 41.540 8x8 BB, 41.540 8x4 BB CH, ; 41.540 8x6 BB CH, 41.540 8x8 BB CH, 32.580 8x4 BB-WW, 32.580 8x4 ; BB, 32.580 8x4 BB CH, 35.580 8x2-4 BL, 35.580 8x4 BB, 35.580 8x4 BL, ; 35.580 8x6H BL, 35.580 8x4H-6 BL, 35.580 8x4-4 BL, 35.580 8x6 BB, ; 35.580 8x8 BB, 35.580 8x4 BB CH, 35.580 8x4 BL CH, 35.580 8x6H BL ; CH, 35.580 8x4H-6 BL CH, 35.580 8x2-4 BL CH, 35.580 8x2-6 BL CH, ; 35.580 8x4-4 BL CH, 35.580 8x6 BB CH, 35.580 8x8 BB CH, 35.580 ; 8x2=4 BL CH, 37.580 8x4 BB, 41.580 8x4 BB, 41.580 8x4 BB-WW, ; 41.580 8x6 BB, 41.580 8x8 BB-WW, 41.580 8x8 BB, 41.580 8x4 BB CH, ; 41.580 8x6 BB CH, 41.580 8x8 BB CH, 32.640 8x4 BB-WW, 32.640 8x4 ; BB, 32.640 8x4 BB CH, 35.640 8x2-4 BL, 35.640 8x4 BB, 35.640 8x4 BL, ; 35.640 8x6H BL, 35.640 8x4H-6 BL, 35.640 8x4-4 BL, 35.640 8x6 BB, ; 35.640 8x8 BB, 35.640 8x4 BB CH, 35.640 8x4 BL CH, 35.640 8x6H BL ; CH, 35.640 8x4H-6 BL CH, 35.640 8x2-4 BL CH, 35.640 8x2-6 BL CH, ; 35.640 8x4-4 BL CH, 35.640 8x6 BB CH, 35.640 8x8 BB CH, 35.640 ; 8x2=4 BL CH, 37.640 8x4 BB, 41.640 8x4 BB, 41.640 8x4 BB-WW, ; 41.640 8x6 BB, 41.640 8x8 BB-WW, 41.640 8x8 BB, 41.640 8x4 BB CH, ; 41.640 8x6 BB CH, 41.640 8x8 BB CH |
Категория ТС | N3, N3G |
Экологический класс | 5 ; 6 |
Заявитель |
|
Заявитель | Общество с ограниченной ответственностью «МАН Трак энд Бас РУС» |
Изготовитель |
|
Предприятие-изготовитель | MAN Truck & Bus SE, |
Сборочный завод |
|
Сборочный завод | Dachauer Strasse 667, D-80995 Munchen, Федеративная Республика Германия |
Орган сертификации |
|
Орган по сертификации | Орган по сертификации механических транспортных средств и прицепов, их составных частей и предметов оборудования "САTР-ФОНД" Межотраслевого Фонда "Сертификация автотранспорта САТР" (ОС "САТР-ФОНД") |
Двигатель внутреннего сгорания |
|
ДВС | MAN, D2066LF41 MAN, D2066LF45 MAN, D2066LF43 MAN, D2066LF47 MAN, D2066LF42 MAN, D2066LF46 MAN, D2066LF40 MAN, D2066LF44 MAN, D2676LF06 MAN, D2676LF08 MAN, D2676LF17 MAN, D2676LF07 MAN, D2676LF09 MAN, D2676LF18 MAN, D1556LF07 MAN, D1556LF10 MAN, D1556LF08 MAN, D1556LF11 MAN, D1556LF09 MAN, D1556LF12 MAN, D2676LF51 MAN, D2676LF66 MAN, D2676LF52 MAN, D2676LF67 MAN, D2676LF53 MAN, D2676LF68 MAN, D2676LF78 MAN, D2676LF84 MAN, D2676LFAB MAN, D2676LFAE MAN, D2676LF79 MAN, D2676LF85 MAN, D2676LF80 MAN, D2676LF86 MAN, D3876LF10 MAN, D3876LF11 MAN, D3876LF12 четырехтактный дизель |
